Alpine A110 Pikes Peak (2023)
Alpine A110 Pikes Peak
The A110 Pikes Peak's turbocharged 1.8-liter engine produces nearly 500 horsepower, a significant increase from the road-going version's 296 hp. Alpine has also managed to further reduce the vehicle's weight to 2,094 pounds (950 kilograms).
TECHNICAL SPECIFICATIONS
| CHASSIS | |
| Type | Aluminium monocoque |
| Safety | Multi-point roll cage |
| Bodywork | Aluminium |
| Aerodynamics | Front splitter with fins, flat bottom, A110 R side skirts, rear fins, A110 R diffuser, rear wing, rear window with integrated shark fin |
| ENGINE | |
| Type | Four-cylinder 1.8-litre 16v |
| Layout | Rear mid-mounted |
| Power | 500hp at 7,500rpm |
| ECU | Magneti-Marelli SRG 140 |
| TRANSMISSION | |
| Type | Rear-wheel drive |
| Gearbox | 3MO six-speed sequential |
| Controls | Steering-wheel mounted |
| Differential | Self-locking, limited slip |
| Clutch | Sintered steel twin-disc |
| AXLES AND SUSPENSION | |
| Suspension | Double Wishbone, Coil Springs & Anti-Roll Bars |
| Shock absorbers | ALP Racing Suspension, 3-way adjustable |
| FR brakes | Ø 355x32mm, six-piston Brembo callipers |
| RR brakes | Ø 300x28mm, four-piston Brembo callipers |
| Steering | Electric power-assisted |
| WHEELS | |
| Rims | Aluminium, 8x17’’ (FR) et 10x18’’ (RR) |
| Tyres | Michelin 20-61x17 (FR) and 27-65x18 (RR) |
| DIMENSIONS, WEIGHT AND CAPACITIES | |
| Length/width/height | 4,230 / 1,850 /1,240 mm |
| Wheel base | 2,415 mm |
| FR/RR tracks | 1,580 / 1,555 mm |
| Fuel tank | FIA FT3 homologated, 25 litres |
| Weight | Approximately 950 kg |
